This document is the user manual for EIZO FlexScan L860, which introduces the product's features, characteristics, usage methods, precautions, etc.
This manual covers safety precautions, installation steps, and adjustment menus for the FlexScan color LCD monitors. It explains how to connect power, video, USB devices, and how to use the on‑screen controls such as Auto EcoView, brightness, contrast, and volume.
Additional sections describe cleaning procedures, ergonomic recommendations, power‑saving features, and troubleshooting tips. The document also includes specifications, a glossary of terms, and optional accessories like adjustable stands and mounting arms. This manual is written in Chinese.
| Maximum power consumption (S2232W) | 80W |
|---|---|
| Maximum power consumption (S2242W) | 80W |
| Maximum power consumption (S2432W) | 90W |
| Effective pixel percentage | 99.9994% or higher |
| Resolution (S2232W) | WSXGA+ (1680×1050) 22‑inch |
The LCD panel needs about 30 minutes after power‑on to stabilize before adjustments.
Yes, the monitor supports portrait mode, but a graphics card that supports vertical display is required.
Do not turn the monitor on until any condensation has disappeared to avoid damage.
