ASRock NF6-GLAN is a motherboard from ASRock's NF6 series. The motherboard uses the Intel 945G chipset and supports Socket 478 processors. The memory supports DDR2 400/533/667/800, and it has two PCI-E x16 slots, two PCI-E x1 slots, two PCI slots, and supports 8-channel audio and Gigabit Ethernet.
This manual identifies the ASRock NF6-GLAN motherboard and lists its key connectors and ports. It includes the model designation and trademark information.
The document details the SATA port layout (four SATAII ports) and the CD drive connector (CD1), as well as other connector markings used for system integration.
| Model | NF6-GLAN |
|---|---|
| SATA Ports | SATAII_1 (PORT 1.0), SATAII_2 (PORT 1.1), SATAII_3 (PORT 2.0), SATAII_4 (PORT 2.1) |
It has four SATAII ports: SATAII_1 (PORT 1.0), SATAII_2 (PORT 1.1), SATAII_3 (PORT 2.0), and SATAII_4 (PORT 2.1).
