This document is the user manual for ALiveNF7G-HD720p, version 2.0/5.0, published in November 2007. The manual contains the features, characteristics, and usage instructions of the product.
This manual covers everything needed to install and configure the ASRock ALiveNF7G‑HD720p motherboard, including package contents, CPU and memory installation, expansion slots, and rear I/O connectors. Detailed BIOS setup instructions and driver installation steps are provided, along with safety warnings and overclocking cautions.
Additional sections describe supported operating systems, 720p Blu‑ray/HD‑DVD playback requirements, and the contents of the support CD, ensuring users can fully utilize the board’s features such as integrated NVIDIA graphics, Gigabit LAN, and 7.1‑channel audio.
| Form Factor | Micro ATX (9.6" x 9.6") |
|---|---|
| CPU Socket | Socket AM2 for AMD Athlon 64FX/64X2/X2/64 and Sempron |
| Chipset | NVIDIA GeForce 7050 / nForce 630A MCP |
| Memory Slots | 4 x DDRII DIMM slots (max 8 GB) |
| Maximum Memory | 8 GB |
| Expansion Slots | 1 x PCI‑Express x16, 1 x PCI‑Express x1, 2 x PCI |
| Audio Codec | ALC888 7.1‑channel HD audio |
| LAN | Gigabit Ethernet (Realtek RTL8211B) |
| BIOS | 4 MB AMI BIOS |
It uses a Socket AM2 that supports AMD Athlon 64FX/64X2/X2/64 and Sempron processors.
The rear panel provides four ready‑to‑use USB 2.0 ports.
Yes, it supports 720p Blu‑ray (BD) / HD‑DVD playback when the proper hardware configuration is used.
The board is compatible with Microsoft Windows 2000, XP, XP Media Center, XP 64‑bit, Vista, and Vista 64‑bit.
