This is a camera user manual, which introduces the features and operation methods of the camera
The manual covers safety precautions, package contents, and basic handling of the camera. It explains the front and rear view components, battery installation, and how to load memory cards.
It also details the camera's operating modes, menu navigation, power management, and driver installation for PC. Technical specifications such as lens, sensor, image resolution, and power requirements are listed, along with system requirements for using the accompanying software.
| Lens focal length | 7.5 mm |
|---|---|
| Image sensor | 1/2" CMOS, 2.0 MP |
| Focus | F=2.8 |
| ISO sensitivity | ISO 100 |
| Shutter speed range | 1/4 sec ~ 1/2000 sec |
| Internal storage | 16 MB Flash |
| SD card support | 4 – 128 MB MMC/SD |
| Maximum image resolution | 2048 × 1536 |
| Digital zoom | 4× (10‑step) |
| Power supply | 2 × AA Alkaline or CRV‑3, USB 5 V |
| Dimensions | 93 × 56 × 38 mm |
| Weight | ≈120 g (batteries excluded) |
The camera is powered by 2 × AA Alkaline batteries, but it also supports CRV‑3 batteries or USB 5 V power.
The camera can capture images up to 2048 × 1536 pixels using its firmware interpolation technology.
It includes 16 MB of internal flash memory and a slot for an SD/MMC card supporting capacities from 4 MB to 128 MB.
