This manual describes how to use the device
This manual provides an overview of the camera’s components, how to set it up, and basic operation steps. It includes safety warnings, package contents, and guidance for using batteries, AC power, and memory cards.
Detailed sections cover still‑image and video recording, playback, camera settings such as resolution, white balance, and flash, as well as how to transfer files to a computer and use the camera as a PC webcam.
| Sensor | 2.0 megapixels CMOS |
|---|---|
| Color depth | 10‑bit |
| Maximum resolution | 1600 × 1200 pixels |
| LCD size | 1.5‑inch color LCD |
| Digital zoom | 2× |
| Memory type | 8 MB internal, SD/MMC external |
| Power source | 2 AA Alkaline or Ni‑MH batteries, CRV3 lithium pack, or AC adapter (2.5 A/3.3 V) |
| Dimensions | 108 mm × 56 mm × 37 mm |
| Weight | 125 g |
The camera can be powered by two AA alkaline or Ni‑MH batteries, a CRV3 lithium battery pack, or an AC power adapter (2.5 A/3.3 V).
The sensor is a 2.0‑megapixel CMOS sensor.
The camera can capture images at up to 1600 × 1200 pixels.
The camera supports SD memory cards and Multi Media Cards (MMC).
