The ASRock WiFi-802.11g Module is an easy-to-use wireless LAN (WLAN) adapter that supports WiFi+AP function. With the ASRock WiFi-802.11g Module, you can easily build a wireless network environment and enjoy the convenience of wireless networking. Therefore, as long as you are in the coverage of the wireless signal, you can play LAN games, connect to Internet, access and share printers, and make phone calls conveniently.
This manual introduces the ASRock WiFi-802.11g wireless LAN module, its specifications, LED indicators, antenna connection, and signal range. It explains how to install the module on a compatible ASRock motherboard, connect the antenna, and install drivers and utility software.
The guide also details configuring the module in Access Point (AP) mode or Station mode, including security settings, SSID management, and advanced options such as network sharing and survey tools. This manual is written in Chinese.
| Standard | IEEE 802.11g |
|---|---|
| Data Transfer Rates | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Security (AP mode) | WEP, WPA |
| Frequency Range | 2.4–2.5 GHz |
| Indoor Signal Range | 80 ft (30 m) |
| Outdoor Signal Range | 200 ft (60 m) |
| Maximum Stations (AP mode) | 16 |
| Antenna Type | Omni‑directional |
| LED Indicator | Green – data transmission |
| Supported OS | Windows XP, Vista (32/64‑bit) |
The AP mode can support up to 16 stations.
The indoor signal range is about 80 feet (30 meters).
It supports Windows XP, Windows XP 64‑bit, Windows Vista and Vista 64‑bit.
AP mode offers OPEN, SHARE WEP and WPA‑PSK TKIP security levels.
