ASRock WiFi-802.11g module is an easy-to-use wireless local area network (WLAN) adapter to support WiFi+AP function. With ASRock WiFi-802.11g module, you can easily create a wireless environment and enjoy the convenience of wireless network connectivity. Therefore, from anywhere within the signal range, you will be able to play LAN games, connect to the internet, access and share printers, and make Internet phone calls easily. Please read this operation guide carefully before you start to set up ASRock WiFi-802.11g module.
The ASRock WiFi-802.11g module is a WLAN adapter that adds Wi‑Fi and AP functionality to compatible ASRock motherboards. It supports IEEE 802.11g, offers up to 16 stations in AP mode, and includes an omni‑directional antenna with a green transmission LED.
This guide covers the module’s technical specifications, hardware and software installation steps, driver and utility installation, and detailed configuration procedures for both Access Point and Station (Infrastructure and Ad‑hoc) modes using the ASRock WiFi‑802.11g Wizard.
| Standard | IEEE 802.11g |
|---|---|
| Data Rate | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Frequency Band | 2.4~2.5 GHz |
| Operating Range (Indoor/Outdoor) | 80 ft (30 m) indoor, 200 ft (60 m) outdoor |
| Maximum Connected Devices (AP mode) | up to 16 stations |
| Supported Operating Systems | Windows XP, XP 64‑bit, Vista, Vista 64‑bit |
The module can support up to 16 stations when operating in Access Point mode.
It works with Windows XP, Windows XP 64‑bit, Windows Vista and Windows Vista 64‑bit.
Turn off the PC, remove the motherboard, fasten the bracket, plug the module into the WiFi or WiFi/E header, secure it with screws, re‑install the motherboard, and connect the antenna cable.
