This document describes the features and characteristics of the ASRock P45XE-WiFiN / P45XE-R / P45XE motherboard.
This guide provides step‑by‑step instructions for installing the ASRock P45XE‑WiFiN, P45XE‑R, and P45XE motherboards. It includes detailed diagrams of the board layout, connector locations, and memory slot identification.
Key sections illustrate the DDRII memory slots (DDRII_A1, DDRII_A2, DDRII_B1, DDRII_B2) and other critical components, helping users correctly assemble and configure the system.
| Memory Slots | DDRII_A1, DDRII_A2, DDRII_B1, DDRII_B2 |
|---|
The board provides four DDRII slots labeled DDRII_A1, DDRII_A2, DDRII_B1, and DDRII_B2.
Each page header shows the model as "ASRock P45XE‑WiFiN / P45XE‑R / P45XE Motherboard".
