HP 8903B Audio Analyzer Operation and Calibration Manual

This document is the operation and calibration manual for HP 8903B AUDIO ANALYZER

Brand: HP
Document type: User Manual
Language: English
Pages: 247
File format: PDF
File size: 14.9 MB
Published: 14 March, 2012
Updated: 30 September, 2023
MD5 checksum: 210240619358C6733BF4233DE608146E
PDF: HP 8903B Audio Analyzer Operation and Calibration Manual PDF

About this manual

This Operation and Calibration Manual for the HP 8903B Audio Analyzer provides essential safety information, product specifications, and detailed procedures for setting up and adjusting the instrument.

It includes sections on general information, audio testing, HP‑IB interface, adjustment steps, and service references, along with warranty and regional service office details.

What's inside

General Information
Safety Considerations
Specifications
Audio Testing
HP‑IB Interface Bus
Compatibility
Options
Adjustment Procedures
Warranty Information
Service and Regional Offices

Specifications

Safety Class	Class I
Installation Category	II
Pollution Degree	2
Line Voltage Input	autoranging
Fuse Rating	250 V

Frequently asked questions

What safety class is the HP 8903B Audio Analyzer?

It is a Safety Class I instrument.

What type of grounding is required for the HP 8903B?

An uninterruptible safety earth ground must be provided from the main power source.

How long is the warranty period for this instrument?

HP warrants the instrument for a period of one year from the date of shipment.

Where can I find the service manual for the HP 8903B?

The Service Manual (Volume 1, 2) is listed as HP Part 08903-90062.
