Fast Track USB is a professional audio interface from M-audio company. It is suitable for any Windows and Mac system. It provides 16 or 24bit digital audio, supports 44.1kHz/48kHz sampling rate. Fast Track USB is small and exquisite. You can carry it with you for music creation or live performance.
The Fast Track USB is a compact USB audio interface that works with Windows and Mac computers. It offers a balanced XLR input, a 1/4" TRS input, stereo RCA inputs and outputs, a headphone output, and supports 16‑24‑bit audio at 44.1 kHz or 48 kHz. The device includes front‑panel indicators for peak and signal levels and a back‑panel with a Kensington lock, USB, and various audio connectors.
Installation is performed by inserting the supplied CD, connecting the USB cable, and following the on‑screen prompts on Windows XP or Mac OS X. After installation, the M‑audio Fast Track USB control panel allows users to adjust gain, monitor levels, select input sources, and configure ASIO or WDM drivers for low‑latency operation. This manual is written in Chinese.
| Mic Input Maximum Level | -2.2 dBu |
|---|---|
| Mic Signal‑to‑Noise Ratio | 100 dB (A‑weighted) |
| Mic THD+N | 0.005% (-86 dB) @ -1 dBFS |
| Mic Frequency Response | 20 Hz – 20 kHz, ±0.2 dB @48 kHz |
| Instrument Input Maximum Level | +3.2 dBV |
| Line‑In Maximum Level | +2.1 dBV |
| Line‑Out Maximum Level | +2.0 dBV |
| Headphone Output Maximum Level | 2.1 Vpp (-2.3 dBV) |
| Supported Bit Depth | 16‑24 bit |
Yes, on Windows XP the Fast Track USB includes Steinberg ASIO drivers for low‑latency operation with compatible audio software.
