AG-MX70 is a video switcher produced by Sony. It supports 100 input channels, can achieve 16 DVE, 9 DSK, 4 overlay, 1 keying output, and is equipped with Dynamic Rounding technology to support 3D image processing. It can realize a variety of special effects processing.
This manual begins with safety precautions, warning users to keep the unit out of sealed enclosures, avoid liquids, and not press the front panel unnecessarily. It also outlines proper installation, power connection, and the use of the included installation CD.
The document then describes the front‑panel controls, external interfaces (GPI, RS‑422A/RS‑232C, USB, BNC), and the many video and audio processing functions such as DSK, color key, luminance key, and 3‑D effects. Memory handling, preset functions, and troubleshooting notes are also covered. This manual is written in Japanese.
| Maximum pressure | 35 VDC |
|---|---|
| Maximum current | 50 mA |
| USB version | 1.1 (max length 3 m) |
| RS‑422A/RS‑232C selectable | D‑sub 9‑pin |
| BNC connectors | 4 inputs (75 Ω) |
Do not install the unit in a sealed enclosure, keep it away from liquids, and avoid pressing the front panel unnecessarily.
