The PT‑X22 is a compact liquid‑crystal projector offering up to 2600 lm brightness, 1000:1 contrast, and a native XGA (1024×768) resolution. It supports multiple video inputs (HD‑15‑pin D‑sub, HDMI, S‑Video, component) and network control via RJ‑45 (PJLink, 100BASE‑TX). The manual details power requirements (100‑240 V AC, 50 Hz), lamp specifications (220 W UHM lamp, ~5000 h life), and environmental limits.
Key features include automatic keystone correction, daylight view mode, smart power management, and remote monitoring through LAN. The guide provides step‑by‑step procedures for lamp replacement, filter cleaning, mounting options, and configuring network and RS‑232C control, ensuring reliable operation in various settings. This manual is written in Chinese.
| Power Supply | 100‑240 V AC, 50 Hz |
|---|---|
| Contrast Ratio | 1000:1 |
| Resolution | 1024×768 (XGA) |
| Throw Ratio | 1.5‑1.7:1 |
| Dimensions (W×H×D) | 307 mm × 69 mm × 210 mm |
