Panasonic KX-NCP500/KX-NCP1000 Virtual SIP Trunk Card Programming Manual

This document is a programming manual for Panasonic Pure IP-PBX, providing information about the features and characteristics of the product.

Brand: Philips
Category: Telephone
Document type: Programming Manual
Language: English
Pages: 52
File format: PDF
File size: 646 KB
Published: 13 March, 2012
Updated: 28 September, 2023
Models: KX-NCP500, KX-NCP1000
MD5 checksum: 09871EBFA7908D8A0C58B904A461821C
PDF: Panasonic KX-NCP500/KX-NCP1000 Virtual SIP Trunk Card Programming Manual PDF

About this manual

This manual explains how to install, configure, and program the V‑SIPGW16 virtual SIP trunk card for Panasonic Pure IP‑PBX models KX‑NCP500 and KX‑NCP1000. It covers network requirements, port settings, NAT traversal, firewall configuration, and bandwidth considerations.

Detailed sections describe IP telephony service information, required ports per channel, firewall and bandwidth requirements, NAT traversal options (STUN or Fixed IP), and how to import/export provider profiles. The document also includes maintenance console operating instructions and configuration management guidance.

What's inside

Information about IP Telephony Service
Important Notice for Subscription and Installation
Port Requirements
Firewall Requirements
Bandwidth Requirements
NAT Traversal
STUN Server
Configuration Management

Specifications

Default SIP Server Port (UDP)	5060
Default STUN Server Port (UDP)	3478
Required RTP Port Range per Channel	UDP 16000‑N

Frequently asked questions

Which NAT traversal methods are supported by the V‑SIPGW16 card?

The card supports STUN and Fixed IP Address methods for NAT traversal.

What is the default UDP port for the STUN client on the V‑SIPGW16 card?

The default STUN client port is UDP 33478.
