This document is the user manual for the SE 710, SE 712, SE 715, and SE 725 stage speakers. The manual provides instructions for operation, safety precautions, and cleaning. Additionally, the manual describes the features and performance of the products.
This manual provides safety instructions, installation guidance, and technical specifications for Phonic's SEM 710, SEM 712, SEM 715 and SE 725 2‑way stage/floor monitor speakers. It includes important warnings about electrical shock, proper cleaning, and recommended usage conditions.
The document also lists the speakers' major features, power handling, woofer sizes, frequency response, sensitivity, impedance, connector types, dimensions, and net weight, as well as warranty, service, and support information.
| Power Handling (RMS / Program) | 150W / 300W (SEM 710), 200W / 400W (SEM 712), 230W / 460W (SEM 715), 400W / 800W (SE 725) |
|---|---|
| Woofer Size | 10" x 1 (SEM 710), 12" x 1 (SEM 712), 15" x 1 (SEM 715), 15" x 2 (SE 725) |
| Frequency Response | 65‑20 kHz (SEM 710), 60‑20 kHz (SEM 712), 50‑20 kHz (SEM 715), 40 Hz ~ 20 kHz (SE 725) |
| Sensitivity @1 W/1 m | 96 dB (SEM 710), 95 dB (SEM 712), 98 dB (SEM 715), 100 dB (SE 725) |
| Nominal Impedance | 8 Ω (SEM 710/712/715), 4 Ω (SE 725) |
| Connector | 2 × 1/4" phone jacks (all models) |
| Dimensions (HxWxD) | 491 × 351 × 314 mm (SEM 710), 540 × 376 × 356 mm (SEM 712), 679 × 476 × 388 mm (SEM 715), 1085 × 476 × 388 mm (SE 725) |
Clean only with a dry cloth, do not use aerosol or liquid cleaners, and unplug the apparatus before cleaning.
Contact an authorized Phonic distributor in your country; Phonic does not release service manuals to consumers.
Use the mains plug as the disconnect device and keep it readily operable.
