This is a user manual for SD camera, which introduces the features of the product, including safety precautions, notes, water resistance, etc.
This manual begins with safety warnings, handling precautions, and waterproof guidelines for the SDR‑SW28GK camcorder, which meets IP58 protection and can be used underwater up to 1.5 m for 30 minutes. It lists all supplied accessories, battery information, and optional items such as hand straps and tripod mounts.
The later sections cover device setup, menu navigation, recording modes, playback functions, editing tools, and connectivity to computers, TVs, and external drives. Detailed specifications for power consumption, sensor resolution, lens optics, and environmental limits are provided, along with troubleshooting tips and a quick‑start guide. This manual is written in Chinese.
| Image sensor | 1/6" CCD, 800 K effective pixels |
|---|---|
| Video resolution | 400 K (4:3), 350 K (16:9) |
| Optical zoom | 10× optical, 25–700× digital |
| LCD monitor size | 2.7 inches, ~123 K pixels |
| Battery type | VW‑VBJ10 |
| Operating temperature range | 0 °C to 40 °C |
It uses the VW‑VBJ10 battery.
The camcorder records video at 400 K effective pixels (4:3) or 350 K (16:9) and still images at 410 K (4:3).
The device is rated for operation between 0 °C and 40 °C.
