The product manual of the TC15 series from Bosch Rexroth AG provides detailed information about their directional control valve products, including 2/2-way, 2/5-way, and 3/5-way valves, as well as accessories and mounting brackets. These valves have features such as high flow rates, pipe connections, and suitability for compressed air.
The Bosch Rexroth TC15 commutation valve series is a pneumatic component designed for linear motion and control applications. This guide provides technical data, performance curves, and installation instructions for the TC15 series.
The document also includes safety notes, operating limits, and contact details for Bosch Rexroth support centers worldwide.
| Maximum flow rate | 1500 l/min |
|---|---|
| Minimum flow rate | 1100 l/min |
| Pressure range | -0.9 bar to 10 bar |
| Operating temperature | 10 °C to 450 °C |
The TC15 valve can handle up to 1500 l/min.
The valve operates between 10 °C and 450 °C.
It is rated for pressures from –0.9 bar up to 10 bar.
