The RA8815 is a graphic LCD driver controller that includes a 266 KB ROM for character fonts, a 528‑byte display RAM, a 256‑byte SRAM for custom characters, and a 354‑byte shift buffer. It supports both Chinese and ASCII character sets and can drive LCD panels up to 128 × 33 pixels with vertical and horizontal scrolling.
The device offers multiple MPU interfaces, including 4‑bit/8‑bit parallel buses and 3‑wire or 4‑wire serial modes, as well as built‑in key‑scan circuitry, voltage‑boost and regulation circuits, and Gold Bump PADs for COG modules. Detailed pin definitions, electrical specifications, and ITO resistance tables are provided for PCB design.
| Maximum LCD panel size | 128 × 33 pixels |
|---|---|
| Operating voltage | 2.5 V – 3.6 V |
| ITO resistance (VDD) | 150 Ω |
The RA8815 can drive LCD panels up to 128 × 33 pixels.
The device operates from 2.5 V to 3.6 V.
