MDX-540 is a desktop-type high-speed milling machine that can quickly and inexpensively produce molds and parts, and is suitable for a variety of material categories, including chemically processed wood, resin, ABS and non-ferrous metals, such as aluminum, brass and copper *.
The MDX-540 PRO II is a rapid‑prototype machine with a compact control panel and a large work area (500 mm × 400 mm × 155 mm). It supports up to four tools, an ATC spindle, and a safety board, allowing 360° multi‑surface cutting of materials such as ABS, wood, and various metals. The machine integrates the Roland SRP Player for tool‑path generation and is compatible with Windows 8, 2000, and XP.
The manual provides installation instructions, safety guidelines, and detailed technical specifications, including spindle speed, power consumption, noise level, and environmental limits. It also lists optional accessories, wiring diagrams, and maintenance procedures for technicians. This manual is written in Japanese.
| Maximum tool diameter | 10 mm (0.4 in) |
|---|---|
| Power consumption | 400 W |
| Operating noise level | 65 dB(A) |
| Operating temperature range | 5‑40 °C (41‑104 °F) |
Up to four tools can be mounted on the ATC spindle.
The SRP Player works with Windows 8, Windows 2000 and Windows XP.
