The document is the operation manual for the SLET1000-B field data acquisition server, which introduces the overview, technical specifications, features, and network topology diagram of the product.
The SLET1000-C is an on‑site data acquisition server designed for online monitoring systems. It collects field data, communicates with a host computer, and monitors system status. The device can connect up to 70 nodes, each with up to 24 channels, supporting a total of 300 channels.
The manual details technical parameters, interface connections (CAN, RS485, fiber optic), installation procedures (wall‑mount with rails), and optional accessories. It also includes a parts list and wiring diagrams to aid setup and maintenance. This manual is written in Chinese.
| Maximum number of nodes | 70 |
|---|---|
| Maximum node number | 100 |
| Maximum channels per node | 24 |
| Total supported channels | 300 |
| Baud rate | 9600 (customizable) |
| Communication ports | CAN, RS485 with fiber isolation |
| Power supply | DC 24 V 1 A |
| Power consumption | 5‑15 W |
| Weight | 3000 g |
| Operating temperature range | -40 °C to +85 °C |
| Dimensions | 200 mm × 70 mm × 175 mm |
It can connect up to 70 nodes.
The default baud rate is 9600, and other rates can be customized.
It requires a DC 24 V, 1 A power supply.
