The NC7SZ04 is a single inverter from Fairchild's Ultra High Speed Series of TinyLogic. The device is fabricated with advanced CMOS technology to achieve ultra high speed with high output drive while maintaining low static power dissipation over a very broad VCC operating range. The device is specified to operate over the 1.65V to 5.5V VCC range. The inputs and output are high impedance when VCC is 0V. Inputs tolerate voltages up to 6V independent of VCC operating voltage.
The NC7SZ04 is a single‑inverter from Fairchild’s Ultra High Speed TinyLogic series. It operates over a broad Vcc range of 1.65 V to 5.5 V, offers high output drive (+24 mA at 3 V), and includes over‑voltage tolerant inputs that accept up to 6 V.
The device is offered in three compact packages—SOT23‑5, SC70‑5, and the lead‑less MicroPak. Detailed absolute‑maximum ratings, DC and AC electrical characteristics, and mechanical dimensions are provided, along with tape‑and‑reel handling specifications.
| Operating Voltage Range (Vcc) | 1.65 V to 5.5 V |
|---|---|
| High Output Drive | +24 mA at 3 V Vcc |
| Typical Propagation Delay | 2.4 ns into 50 pF at 5 V |
| Input Voltage Tolerance | Up to 6 V independent of Vcc |
The device operates from 1.65 V up to 5.5 V Vcc.
It can source up to +24 mA at a 3 V supply.
The part is offered in SOT23‑5, SC70‑5, and a lead‑less MicroPak package.
Typical propagation delay is 2.4 ns into a 50 pF load at 5 V.
