Motion-SPM is a series of intelligent power modules from Fairchild Semiconductor. This series of modules uses µMini-DIP SPM® packaging technology, and its main features include: smaller size, lower power consumption, and higher reliability. This series of modules is designed for inverter-powered household appliances-motor drive systems, including air conditioners, washing machines, refrigerators and fans.
The AN-9070 is a Mini‑DIP SPM packaged Motion‑SPM power module aimed at home‑appliance motor‑drive applications such as air‑conditioners, refrigerators, washing machines and fans. It integrates a low‑loss IGBT, a fast‑recovery FRD diode, an internal NTC thermistor for temperature monitoring, and built‑in gate‑driver ICs (HVIC/LVIC) with UVLO and short‑circuit protection.
The document provides design guidelines, key parameters, component selection advice (shunt resistors, bootstrap capacitors), pin‑out and footprint drawings, typical application circuits, and detailed packaging information for bulk shipping.
| Rated voltage / current | 600 V, 20 A |
|---|---|
| Isolation voltage rating | 2000 V (1 min) |
| Package dimensions | 39 mm × 23 mm |
| IGBT saturation voltage (10 A) | 1.0 V |
| Operating temperature range | 25 °C – 125 °C |
The package measures 39 mm by 23 mm.
The module is rated for 2000 V isolation for up to one minute.
