The Fluke 576 infrared thermometer is a non‑contact temperature measurement device that determines surface temperature by detecting infrared radiation. It also includes a built‑in digital camera for recording temperature data with images.
This manual covers safety warnings, battery handling, laser operation, camera usage, technical specifications, calibration, fault diagnosis, and maintenance procedures, as well as CE certification information. This manual is written in Chinese.
| Temperature range (standard) | -30 °C … 900 °C |
|---|---|
| Display resolution | 0.1 °C |
| Accuracy (standard, 25 °C ambient) | ±0.75 % or ±0.75 °C |
| Optical resolution (standard focus) | 60:1 (spot size 19 mm at 1.15 m) |
| Response time (95 %) | 250 ms |
| Power source | 2 × 1.5 V AA alkaline batteries |
| Dimensions | 240 × 170 × 50 mm |
| Analog output (optional cable) | 1 mV/°C |
Fluke guarantees the product for one year from the date of purchase.
It is powered by two AA 1.5 V alkaline batteries.
The 95 % response time is 250 ms.
