This document is the user manual for DTX Series CableAnalyzer™, describing the features and characteristics of the product.
This manual covers the DTX Series handheld cable testers, describing their physical characteristics, power options, and safety precautions. It explains how to set up tests for twisted‑pair and coaxial cabling, perform automatic certification, and interpret pass/fail results.
Additional sections detail memory management, software updates via LinkWare, optional modules (OTDR, PoE, 10 G), and warranty information. The document is written in Simplified Chinese and includes a full index for quick reference. This manual is written in Chinese.
| Battery runtime | At least 12 hours continuous operation |
|---|---|
| Internal storage capacity | Up to 250 automatic test results |
| Removable memory card capacity | Up to 500 test results on 16 MB card |
| Display type | Color LCD showing pass/fail status |
The rechargeable lithium‑ion battery provides at least 12 hours of continuous operation.
Up to 250 automatic test results can be saved internally.
A 16 MB removable memory card can hold up to 500 test results.
