The Fluke F199S is a high-performance, portable oscilloscope that offers 200MHz bandwidth, 2.5GS/s real-time sampling rate and advanced memory and triggering capabilities. It also features a rugged, compact, and battery-powered design.
The Fluke F199S universal ScopeMeter combines oscilloscope, multimeter, and paperless recorder functions in a portable, battery‑operated unit. It offers up to 200 MHz bandwidth, 2.5 GS/s real‑time sampling, and advanced trigger modes, including automatic and manual options with external isolation.
The instrument provides powerful analysis tools such as 24 automatic measurements, cursor readout, image magnification, and a 4‑hour rechargeable battery that can run up to four hours continuously. Memory depth reaches 27,500 points per channel, and the device can automatically capture and replay the latest 100 waveform screens. This manual is written in Chinese.
| Maximum real‑time sampling rate | 2.5 GS/s |
|---|---|
| Rise time (typical) | 2.0 ns |
| Channels | Dual channel + external trigger / digital channels |
| Timebase range | 5 ns – 2 min/div |
| Vertical sensitivity | 5 mV – 100 V/div |
| Memory depth per channel | 27,500 points |
| Automatic measurements | 24 |
| Battery operation time | ≈4 hours (rechargeable) |
| Dimensions | 256 × 169 × 64 mm |
| Weight | 1.95 kg |
The instrument includes 24 automatic measurement functions.
The rechargeable battery supplies about four hours of continuous operation.
The device automatically stores the latest 100 waveform screens for replay.
