The CC880 (Solution 16) Control Master is a component of residential and commercial electronic monitoring systems. It supports 16 zones, eight of which use programmable end-of-line (EOL) resistors. Up to 16 zones can be achieved by adding an eight-zone expansion board or using the zone doubling feature.
The CC880 (Solution 16) control master is a security system controller for residential and commercial use, supporting up to 16 zones with optional zone‑doubling. It offers basic functions such as PIN code management, four programmable zones, near‑range programming via MS‑DOS PC, DTMF remote programming, and three arming modes (AWAY, STAY 1, STAY 2). The device also includes automatic battery testing, event playback, and fault detection.
Installation details cover hardware dimensions (30.6 cm × 26.2 cm × 8.4 cm), weight (2.5 kg), operating temperature (0 °C to +45 °C), humidity range (10 % to 95 %), and power requirements (240 VAC to 18 VAC, 1.3 A). Power consumption figures are 65 mA standby, 115 mA alarm, and 105 mA for other functions. Compatibility with various RF receivers, remote controls, and accessory panels is also listed. This manual is written in Chinese.
| Dimensions | 30.6 cm × 26.2 cm × 8.4 cm (12 in × 10.3 in × 3.3 in) |
|---|---|
| Weight | 2.5 kg |
| Operating Temperature | 0 °C to +45 °C |
| Relative Humidity | 10 % to 95 % |
| Power Supply | 240 VAC to 18 VAC, 1.3 A |
| Standby Current | 65 mA |
