The Endress+Hauser Promag 10H manual provides detailed information on system design, measurement principles, and electrical connections. It includes installation guidelines, performance features, and certification details for hygienic and industrial applications.
Key sections cover flow measurement range, temperature and pressure limits, power supply options, and wiring diagrams, helping users configure and maintain the system safely and accurately. This manual is written in Chinese.
| Maximum flow measurement | 4.700 ma |
|---|---|
| Maximum fluid temperature | +150 °C |
| Maximum process pressure | 40 bar |
| Power consumption (85‑250 VAC) | <12 VA (including sensor) |
| Power consumption (20.28 VAC) | <8 VA (including sensor) |
| Power consumption (11.40 VDC) | <6 VA (including sensor) |
The system can measure up to 4.700 ma.
The maximum fluid temperature is +150 °C.
The system is rated for up to 40 bar process pressure.
