Endress+Hauser Gammapilot MFMG60 Radiation Instrument User Manual

About this manual

The Gammapilot MFMG60 is an integrated transmitter for non‑contact level, interface and density measurement, suitable for harsh and explosive environments. It combines a scintillator, photomultiplier tube and processing electronics to convert gamma radiation into a proportional measurement signal.

The manual covers installation of the gamma source and transmitter, measurement principles, linearisation, communication options (HART, PROFIBUS‑PA), safety certifications (ATEX, SIL2) and maintenance procedures, including remote display and pneumatic ON/OFF circuit options. This manual is written in Chinese.

What's inside

• Measurement Principles
• Level and Interface Detection
• Density and Concentration Measurement
• Communication Interfaces (HART, PROFIBUS‑PA)
• Safety and Certifications
• Mechanical Design and Installation
• Service Interface Operation
• Remote Display and Pneumatic ON/OFF Circuit
