This document introduces the features and characteristics of the TI 047D/06/zh No. 50096459 product, including the communication interfaces that can be connected to various process control systems, such as HART standard interface, PROFI BUS-PA, and PROFI BUS-DP interfaces, Foundation Fieldbus, etc. This product can be used to measure the flow rate of fluids with a conductivity of 5s/cm, and is suitable for measuring acids, alkalis, coatings, paints, pastes, slurries, water, wastewater, etc. The product has high measurement accuracy, which is beneficial to improve process control quality. The product features include explosion-proof certification, suitable for the chemical and petrochemical industries, nominal diameter range of DN15...600, installation length compliant with DVGW and ISO standards, optional measurement accuracy of 0.5% or 0.2%, suitable for explosion-proof environments, with photoelectric key operation, expandable software package, diagnostic function, and quick setup menu for field debugging, etc.
This manual provides detailed information on the Promag50 and Promag53P flow measurement devices, including their operating principles, configuration parameters, and connection diagrams. It also lists safety and environmental requirements such as ATEX and FMCSA compliance.
The document contains electrical specifications, mechanical dimensions, calibration procedures, and communication options (HART, PROFIBUS‑PA/DP). Users can find wiring tables, pressure ratings, and performance data to correctly install and maintain the instruments in industrial or chemical processes. This manual is written in Chinese.
