This manual provides information on installing and operating APC metered rack power distribution units (PDUs). Each PDU includes a sensor to measure the current used by the PDU and the devices connected to it, and can be monitored via the Web, Telnet, SSH, SNMP, or InfraStruXure Manager interfaces.
The APC Metered Rack Power Distribution Unit (PDU) includes a built‑in sensor that measures the current used by the PDU and all connected equipment. The unit can be monitored via a web interface, Telnet, SSH, SNMP, or the InfraStruXure Manager.
The manual covers unpacking, rack mounting (tool‑free or bracket installation), wiring, network and serial setup, quick configuration of TCP/IP settings, password recovery, firmware updates, and warranty information. This manual is written in Chinese.
| Current measurement sensor | Measures total current of the PDU and connected devices |
|---|---|
| Display interface | Shows total current and alerts when thresholds are exceeded |
| Network interface | Ethernet (CAT5) port for web, Telnet, SSH, SNMP access |
| Serial port | RJ‑11 modular port with supplied cable (part 940‑0144) |
Follow the password recovery procedure described in the "密码丢失恢复" section of the manual.
Download the firmware update using the steps in the "如何下载固件更新" section.
