RP504x series is a low supply current CMOS-based PWM/VFM step-down DC/DC converter with synchronous rectifier. RP504K/L can be switched from two control types by inputting signal to the MODE pin - forced PWM control or PWM/VFM auto switching control in which mode automatically switches to high-efficiency VFM mode in low output current. (RP504N Series can be selected from forced PWM control or PWM/VFM auto switching control.) RP504x includes a soft start circuit, an under-voltage lockout circuit (UVLO), and a latch protection circuit. By simply using an inductor and capacitors as external components, a high-efficiency step-down DC/DC converter can be easily configured. The small inductor (2.2μH) and output capacitor (4.7μH) can be used by the switching of 2.25MHz. In addition to SOT-23-5 and DFN1616-6B packages, a 1.2mm × 1.6mm DFN(PLP)1216-6B package is also available.

The RP503x Series are low supply current CMOS-based 600mA∗ step-down DC/DC Converters with synchronous rectifier. Each of these ICs consists of an oscillator, a switching control circuit, a reference voltage unit, an error amplifier, a soft-start circuit, UVLO circuit, a latch protection circuit, switching transistors, and so on. A low ripple, high efficiency step-down DC/DC converter can be easily composed of this IC with only an inductor and capacitors. In terms of the output voltage, since the feedback resistances are built-in, the voltage is fixed internally. 0.1V step output can be set by laser-trim and 1.5% or 18mV tolerance depending on the output voltage is guaranteed. RP503x is PWM/VFM auto switching control in which mode automatically switches from PWM mode to high-efficiency VFM mode in low output current. The efficiency in low output current (VFM mode) improved compared with existing products. As protection circuits, the current limit circuit which limits peak current of Lx at each clock cycle, and the latch type protection circuit which works if the term of the over-current condition keeps on a certain time exist. The latch-type protection circuit works to latch an internal driver with keeping it disable. To release the condition of the protection, after disabling this IC with a chip enable circuit, enable it again, or restart this IC with power-on or make the sup

The RP503x series is a low supply current CMOS-based PWM/VFM step-down DC/DC converters with synchronous rectifier. RP503x is PWM/VFM auto switching control in which mode automatically switches to high-efficiency VFM mode in low output current. The efficiency in low output current (VFM mode) improved compared with existing products. RP503x includes a soft start circuit, an under-voltage lockout circuit (UVLO), and a latch protection circuit. By simply using an inductor and capacitors as external components, a high-efficiency step-down DC/DC converter can be easily configured.

The RP502x series of synchronous rectifier step-down DC/DC converters are based on the CMOS process. They contain an oscillator, a reference voltage unit, an error amplifier, a switching control circuit, a soft-start circuit, protection circuits, an UVLO circuit, and switching transistors. Using built-in switch transistors for synchronous rectification, a high-efficiency step-down DC/DC converter is composed of only an inductor and capacitors. As protection circuits, the ICs contain a current limit circuit and a latch protection circuit. The current limit circuit controls the peak current of LX at each clock cycle. If the load current exceeds the limit value for a certain period of time, the latch protection circuit maintains the built-in driver in OFF state. To cancel the latch protection, disable the ICs with a chip enable circuit and then enable it again, or make the power supply voltage lower than UVLO. The setting voltage for the RP502x series is the output voltage fixed type with built-in feedback resistance that is adjustable in 0.1V step with the accuracy of ± 1.5% or ±24mV. The packages for the ICs are WLCSP-6-P2 and DFN1616-6, which enable the high-density mounting. The switching mode for the ICs is selectable from the PWM/VFM auto switching type, which achieves the high efficiency at the light load condition or PWM fixed type, which switches at the fixed frequency.

PASCAL Ci is a new type of pressure transmitter in the PASCAL series. It uses 2-wire communication and a 4-20 mA analog output. The measuring range is 16 mbar to 400 bar, with an accuracy of 0.2%. It has overpressure protection, undervoltage protection, and self-calibration functions.

This document is the instruction manual for the HI 96804 refractometer, which describes the specifications, operating principles, functional descriptions, display elements, warnings, error messages, calibration procedures, measurement procedures, changing temperature units, battery replacement, and warranty of the refractometer.

The RP502x Series are low supply current CMOS-based PWM/VFM step-down DC/DC converters with synchronous rectifier. RP502x can be selected from two control types - fixed PWM control or PWM/VFM auto switching control in which mode automatically switches to high-efficiency VFM mode in low output current. RP502x includes a soft start circuit, an under-voltage lockout circuit (UVLO), and a latch protection circuit. By simply using an inductor and capacitors as external components, a high-efficiency step-down DC/DC converter can be easily configured. The small inductor (1.0μH/2.2μH) and small output capacitor (4.7μF) can be used by the switching of 3.3MHz.

This document is the instruction manual for the HI 96803 refractometer for glucose measurements, describing the features and characteristics of the product.

TKA DI 2000 is a mixed-bed system for deionized water from TKA brand. It has an efficient water flow path, can produce the amount of pure water you need, can eliminate quality loss during storage, and prevent algae growth by blue light protection. It is pressure resistant up to 10 bar and has digital conductivity monitoring, which is clean and environmentally friendly.

RP501K series are CMOS-based step-down DC/DC converters with synchronous rectifier.

This document is an instruction manual for the HI 96802 refractometer for fructose measurements. It provides information on the features and usage of the instrument.

The RP501K series are low supply current CMOS-based PWM/VFM step-down DC/DC converters with synchronous rectifier. RP501K can be selected from two control types by input signal to the MODE pin - fixed PWM control or PWM/VFM auto switching control in which mode automatically switches to high-efficiency VFM mode in low output current. RP501K includes a soft start circuit, an under-voltage lockout circuit (UVLO), and a latch protection circuit. By simply using an inductor and capacitors as external components, a high-efficiency step-down DC/DC converter can be easily configured. The small inductor (2.2μH) can be used by the switching of 2.25MHz. The frequency accuracy improved to ±10%.

The document describes the features and characteristics of Thermo Scientific ion exchange resins, including the production of deionized water and fully demineralized water for high purity water systems, as well as ion exchange resin regeneration with TOC control. It also highlights the quality monitoring of Thermo Scientific ion exchange resins and the appropriate systems for various needs.
