transformer models by brand
Featured transformer manuals
Chint NDKQ-100 Power Transformer Product Leaflet
The NDKQ-100 is part of Chint's TDR series of control transformers, designed for use in CNC machines, office automation equipment, and audio‑visual systems where the supply voltage does not exceed 500 V and the frequency is 50/60 Hz.
The document lists key technical data such as a 100 VA output capacity, 50 Hz frequency, 380 V rated input voltage and 36 V rated output voltage, along with environmental limits (‑5 °C to 40 °C, altitude ≤2000 m, humidity ≤95 %). It also includes ordering details, dimensional drawings, and compliance with standard Q/ZT 285. This manual is written in Chinese.
Covers: Product Name · Model · Output Capacity · Frequency · Rated Input Voltage · Rated Output Voltage
Bothhand 10/100 BASE Pulse Transformers (SMD) Datasheet
This datasheet describes Bothhand's 10/100 BASE pulse transformers in a small‑size SMD package. The devices are designed to meet IEEE 802.3u requirements, feature a 350 µH OCL with 8 mA bias, and comply with RoHS and Halogen‑Free standards. Operating temperature ranges from 0 °C to +70 °C, with storage limits of –25 °C to +85 °C.
Key specifications include insertion loss, return loss, cross‑talk, and a 1:1 turns ratio (±5%). Mechanical data cover packaging options such as reels, inner boxes, and cartons. Contact information for sales and technical support is provided at the end of the document.
Covers: Electrical Specifications · Mechanical Specifications · Packaging · Compliance · Contact Information
BKC BKC-150 Control Transformer Manual
This manual describes the BKC series control transformer, intended for use in machine tools and mechanical equipment operating on 50 Hz/60 Hz AC power. It outlines the purpose, features, and typical applications of the device.
The document lists technical specifications such as output capacity, frequency, rated voltages, and environmental limits, as well as installation dimensions and recommended operating conditions. It also includes a product data table for various BKC models. This manual is written in Chinese.
Covers: Purpose · Model and specifications · Operating conditions and installation · Features · Dimensions and installation size · Product information
Latest transformer manuals
Chint NDKQ-100 Power Transformer Product Leaflet
Product Leaflet 2 pages · 707 KB · ZHThe Chint NDKQ-100 power transformer leaflet provides specifications, dimensions, installation guidelines, and ordering information for the TDR series.
Bothhand 10/100 BASE Pulse Transformers (SMD) Datasheet
Datasheet 3 pages · 631 KB · ENThe Bothhand 10/100 BASE Pulse Transformers (SMD) datasheet provides electrical, mechanical, and compliance specifications.
Bothhand USA TS8121V LF(M) transformer
Designed to meet IEEE 802.3u requirement,including 350uH OCL with 8mA bias. Comply with RoHS requirements-whole part No Cd, No Hg,No Cr6+,No PBB and PBDE and No Pb on external pins. Operating temperature range: 0
BKC BKC-150 Control Transformer Manual
User Manual 2 pages · 678 KB · ZHThe BKC BKC-150 control transformer manual provides specifications, installation conditions, dimensions, and operating guidelines.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in transformer manuals
What is the rated output capacity of the NDKQ-100 transformer?
The NDKQ-100 has a rated output capacity of 100 VA.
What is the maximum altitude for reliable operation?
It can operate reliably at altitudes up to 2000 m.
What are the operating temperature limits for the Bothhand 10/100 BASE pulse transformers?
The operating temperature range is 0 °C to +70 °C.
From: Bothhand 10/100 BASE Pulse Transformers (SMD) Datasheet
Do the transformers comply with RoHS and Halogen Free standards?
Yes, they comply with RoHS and Halogen Free requirements.
From: Bothhand 10/100 BASE Pulse Transformers (SMD) Datasheet
What is the maximum operating altitude?
The transformer can operate up to an altitude of 2000 m.
