Key facts
- Brand
- SIRIUS
- Model
- Stratus 5
- Category
- Car Accessories
- Documents
- 2
- Languages
- EN
- Last added
- 2012-07-06
Start here
SIRIUS Stratus 5 Dock & Play Radio User Guide
This manual provides instructions for setting up and using the SIRIUS Stratus 5 Dock & Play Radio. It details how to install the vehicle dock, connect the magnetic antenna and cigarette lighter adapter, and subscribe to the service. The guide also explains how to use the front panel controls for channel selection, FM transmission, and menu navigation.
Read onlineSIRIUS Stratus 5 specifications
| Operating Temperature | -20° to +85° C (-4° to +185° F) |
|---|---|
| Radio Dimensions | 114mm x 48mm x 15mm |
| Radio Weight | 85g |
| Satellite Frequencies | 2322.293/2330.207 MHz |
| Terrestrial Frequencies | 2326.250MHz |
| Radio Power Requirements | 4.9 – 5.6 Volts, Negative Ground, DC |
| Audio Output | 700mVrms (+/- 50mVrms) |
| Total Harmonic Distortion | <0.2% |
| Signal-to-noise | Greater than 73dB |
| Fuse Requirement | 2A ATC |
| Cable Length | 21' |
All SIRIUS Stratus 5 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
What is the operating temperature range for the Stratus 5?
The radio is designed to operate between -20° to +85° C (-4° to +185° F).
How do I power the Vehicle Dock?
It must be powered from the vehicle's cigarette lighter or similar power port using the included adapter.
Where should the FM extender antenna be mounted?
The FM extender antenna should be mounted vertically on the inside of the windshield at the edge of the glass nearest the antenna.
From: SIRIUS Stratus 5 Satellite Radio Vehicle Kit Installation Guide
How do I activate the radio?
To activate the radio, find the 12 digit SIRIUS ID number on the bottom of the box or by selecting power > Menu > SIRIUS Id, then subscribe online or by phone.
From: SIRIUS Stratus 5 Satellite Radio Vehicle Kit Installation Guide
