Start here
RENESAS M16C/62P Group (M16C/62P M16C/62PT) Hardware Manual
This hardware manual describes the M16C/62P Group of 16‑bit single‑chip microcomputers. It is intended for engineers and designers who have basic knowledge of electric and logical circuits and need detailed information on the device's architecture, registers, and peripheral functions.
The document includes a block diagram, pin configuration, CPU register set, memory map, special function registers, reset behavior, clock generation, protection features, interrupt handling, watchdog timer, DMA controller, and timer modules. It also contains safety notices and guidance on obtaining the latest revision from Renesas' website.
Renesas M62P specifications
| Microcontroller | M30626FJPGP |
|---|---|
| Input Clock Main | 6 MHz |
| Input Clock Sub | 32.768 kHz |
| LED Power indicator | green x 1 |
| DC Power Jack | 5 V Input |
| RS232 Serial Connector | 9‑pin DSUB |
| LCD Display Connector | 14‑pin socket |
All Renesas M62P documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What microcontroller is used on the Renesas M16C/62P Starter Kit?
The kit uses the M30626FJPGP microcontroller.
How can the starter kit be connected to a host PC?
It can be connected via a simple RS232 serial connection (not normally fitted) or through the included USB E8a on‑chip debugging interface.
How can I verify that I have the most up‑to‑date version of this manual?
Visit the Renesas website and check for the latest revision before using the material.
From: RENESAS M16C/62P Group (M16C/62P M16C/62PT) Hardware Manual
What is the address space of the M16C/62P microcontroller?
The M16C/62P provides a 1 Mbyte address space, which can be expanded to up to 4 Mbytes with memory‑space expansion.
From: Renesas M16C/62P/62PT Single-Chip 16-Bit CMOS Microcomputer Hardware Manual
How many basic instructions does the M16C/62P support?
The CPU core implements 91 basic instructions.
From: Renesas M16C/62P/62PT Single-Chip 16-Bit CMOS Microcomputer Hardware Manual
