Key facts
- Brand
- Murata
- Model
- CSTCE20M0V53C-R0
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-01-14
Start here
murate CSTCE20M0V53C-R0 Evaluation Data of CERALOCK Oscillation Circuit Manual(1)
This document provides the evaluation data for the Murata CSTCE20M0V53C-RO ceramic resonator when used in the CERALOCK® oscillation circuit. It includes technical data, test measurements, and analysis of performance under various supply voltages and temperatures.
Key sections cover supply voltage range, temperature range, load capacitance, input voltage thresholds, rise time definition, frequency correlation, and comparison tables of measured parameters. Appendices describe rise‑time measurement methodology and frequency‑correlation considerations.
Murata CSTCE20M0V53C-R0 specifications
| Part Number | CSTCE20M0V53C-RO |
|---|---|
| Load Capacitance (C1) | 15 pF |
| Input Low Voltage (VIL) | -0.2 V |
Source: murate CSTCE20M0V53C-R0 Evaluation Data of CERALOCK Oscillation Circuit Manual(1)
All Murata CSTCE20M0V53C-R0 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
How is rise time defined in this evaluation report?
Rise time is the time required to reach 90 % of the oscillation level under steady‑state conditions.
From: murate CSTCE20M0V53C-R0 Evaluation Data of CERALOCK Oscillation Circuit Manual(1)
What is the typical load capacitance of the resonator?
The typical load capacitance (C1) is 15 pF.
From: murate CSTCE20M0V53C-R0 Evaluation Data of CERALOCK Oscillation Circuit Manual(1)
What is the supply voltage range for the CSTCE20M0V53C-RO resonator?
The resonator operates with a supply voltage ranging from 2.7 V to 5.5 V.
From: murate CSTCE20M0V53C-R0 Evaluation Data of CERALOCK Oscillation Circuit Manual(1)(1)
