Murata BL01 BL02 BL03 Series EMI Leaded Filters Datasheet
The BL01, BL02 and BL03 series are Murata leaded EMI filters designed for high‑density printed‑circuit‑board applications such as micro‑computers, switching regulators, digital control equipment and automotive radios. Both axial and radial lead versions are offered, with single‑bead and double‑bead constructions for enhanced noise suppression.
The document provides a complete part‑numbering system, electrical characteristics (permeability, saturation flux, coercive force, Curie point, temperature coefficient, loss factor, resistivity), mechanical dimensions, and packaging options (tape, reel, bulk, ammo). All parts are available through authorized Murata Electronics distributors.
Murata BL01 specifications
| Permeability (μ) | 550 |
|---|---|
| Saturation Magnetic Flux Density (Bs) | 3100 gauss |
| Coercive Force (Hc) | 0.3 Oe |
| Curie Point (Tc) | 130 °C |
| Temperature Coefficient (α) | 20 × 10⁻⁶ /°C |
| Relative Loss Factor (DF) | 0.5 MHz |
| Resistivity (ρ) | 10⁷ Ω·m |
| Maximum Rated Current (Bulk) | 7 A |
| Maximum Rated Current (Taped) | 6 A |
| Operating Temperature | -25 °C to +85 °C |
All Murata BL01 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What applications are the BL01/BL02/BL03 filters used for?
They are used in micro computers, switching regulators, digital control equipment, car radios, and car stereos.
What is the maximum rated current for the BL01/BL02 series?
The bulk‑packaged units are rated for 7 A, while taped units are rated for 6 A.
