Foxconn P67A/P67A-S Motherboard User Manual
This manual covers the Foxconn P67A/P67A-S series motherboard, detailing its hardware layout, back‑panel connectors, and supported components. It includes product specifications, CPU and memory compatibility, expansion slots, storage interfaces, and USB ports.
Installation procedures, BIOS configuration, RAID setup, and software utilities such as FOX ONE and LiveUpdate are described, along with safety warnings, ESD precautions, and environmental compliance information. This manual is written in Chinese.
Foxconn P67A specifications
| CPU socket | LGA1155 (Intel CPUs, max 95W) |
|---|---|
| Chipset | Intel H61 |
| Memory slots | 2 x 240‑pin DDR3 DIMM, up to 8 GB, 1333/1066 MHz |
| PCI Express slots | 1 x PCIe x16, 3 x PCIe x1, 2 x PCI |
| SATA ports | 4 x SATA 2.0 (300 MB/s, hot‑plug, NCQ) |
| Network controller | Realtek RTL8111E Gigabit Ethernet |
| Audio codec | Realtek ALC662 (HD Audio, 5.1, S/PDIF) |
| USB ports | 10 x USB 2.0 (6 rear, 4 via internal headers) |
| Form factor | ATX, 24.4 cm × 19.8 cm |
All Foxconn P67A documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What should be worn to prevent static discharge damage when handling components?
An anti‑static wrist strap should be worn while touching electronic parts.
How many USB 2.0 ports does the P67A1 motherboard provide?
The board provides ten USB 2.0 ports – six on the rear panel and four via two internal headers.
