Key facts
- Brand
- Actron
- Model
- CP7665
- Industry
- Industrial
- Documents
- 3
- Languages
- FR · ES · EN
- Last added
- 2012-06-05
Start here
Actron CP7665 AutoAnalyzer User Manual
This document is a French-language user guide for the Actron CP7665 AutoAnalyzer. It details the device's basic measurement functions such as DC voltage, resistance, diode testing, and battery control. The manual also explains how to use the tool for specific automotive diagnostics including fuse checks, ignition circuits, fuel injectors, and various engine sensors like oxygen and temperature sensors. This manual is written in French.
Read onlineActron CP7665 specifications
| DC Volts Range | 0 to 500V |
|---|---|
| Resistance Range | 0.1Ω to 20MΩ |
| AC Volts Range | 0 to 500V |
| DC Amps Range | 0 to 10A |
Source: Actron CP7665 Automotive Tester Operating Instructions
All Actron CP7665 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum DC voltage this multi-analyzer can measure?
The device measures continuous current voltages from 0 to 450 V.
What is the maximum DC current measurement capability?
The device allows measuring continuous current intensity from 0 to 10A.
What battery is required for the CP7665?
The manual states that a 9 Volt battery must be installed before using the digital multimeter.
From: Actron CP7665 Automotive Tester Operating Instructions
How do I know if the range is set correctly?
The multimeter should be set in the lowest possible range without overranging; if '1' or '- 1' appears, increase the range.
From: Actron CP7665 Automotive Tester Operating Instructions
