The ZTE ZXA10 C300 introduction outlines its high‑capacity vertical plug‑in card, rack options, PON features, uplink interfaces and physical specifications.
The ZXA10 C300 is a high‑capacity, vertical plug‑in card with front‑access design. It supports two rack configurations – 23 slots for a 21‑inch rack and 21 slots for a 19‑inch rack – and can serve up to 16,384 GPON subscribers. The system provides multiple uplink options, including GE and 10GE optical ports, as well as TDM interfaces such as T1/E1 and STM‑1/STM‑4.
The platform offers extensive L2/L3 features, QoS, MPLS, and security functions, including AES‑128 encryption, VLAN stacking, and anti‑DoS mechanisms. Physical specifications include operating temperatures from –25 °C to +55 °C, humidity range 5 %–95 %, and a working voltage of –48 V DC (±20 %) or –60 V DC (±20 %).
| Rack slots | 23 slots for 21" rack, 21 slots for 19" rack |
|---|---|
| Maximum GPON subscribers | 16384 |
| Uplink interfaces | 4×GE (Optical), 2×10GE + 2×GE or 4×10GE (Optical) |
| Operating temperature | -25 °C to +55 °C |
| Operating humidity | 5 % – 95 % |
| Working voltage | -48 V DC (±20 %) or -60 V DC (±20 %) |
| Maximum input current | 50 A |
It can support up to 16,384 GPON subscribers.
The device provides 4×GE (Optical) ports and either 2×10GE + 2×GE or 4×10GE (Optical) ports, plus TDM uplinks such as T1/E1 and STM‑1/STM‑4.
The equipment operates from –25 °C up to +55 °C.
It supports a 23‑slot configuration for a 21‑inch rack and a 21‑slot configuration for a 19‑inch rack.
