The ZTE ZXDSL 9806H is a GPON optical network unit for FTTB/FTTC, supporting POTS, ADSL2+, VDSL2 and up to 2.488 Gbps downstream.
The ZXDSL 9806H is a small‑sized GPON optical network unit designed for FTTB/FTTC deployments. It provides POTS, FE, ADSL2+/SHDSL/VDSL2 access and a GPON interface to connect the OLT with an ODN. The device supports VoIP, Internet, IPTV services and a range of QoS features such as SP, WRR, VLAN tagging and multicast handling.
Key technical data include downstream/upstream rates of 2.488 Gbps/1.244 Gbps, a maximum GPON link distance of 20 km, and power consumption of 75.8 W at full load. The unit can be powered by –48 V DC or 110/220 V AC, fits in a rack, cabinet, desktop or pole, and operates from –45 °C to 55 °C with humidity up to 100 %.
| Downstream data rate | 2.488 Gbps |
|---|---|
| Upstream data rate | 1.244 Gbps |
| User side interface | 10/100 Mbps auto‑negotiation |
| Maximum link distance | 0 ~ 20 km |
| Receiving wavelength | 1,490 nm |
| Transmitting wavelength | 1,310 nm |
| Receiving sensitivity | Better than –29 dBm |
| Optical power overload | 1 ~ 5 dBm |
| Power consumption | 75.8 W (128 lines ADSL2/2+) |
| Dimensions (H × W × D) | 88 mm × 482.6 mm × 240 mm |
| Operating temperature | -45 °C ~ 55 °C |
| Operating humidity | 5 % ~ 100 % |
| Weight | < 8.5 kg |
| Power supply | -48 V DC or 110/220 V AC |
| Mounting mode | Rack, Cabinet, Desktop, Pole |
It provides up to 2.488 Gbps downstream and 1.244 Gbps upstream.
The GPON link can reach up to 20 km.
The device operates from –45 °C to 55 °C.
It can be powered by –48 V DC or by 110 V/220 V AC.
