The Trimble Condor Series GPS Modules User Guide provides setup instructions, safety information, specifications, and interface details.
This user guide covers the Condor Series GPS modules, including safety warnings, handling procedures, warranty terms, and basic product information. It explains how to set up the starter kit, connect the carrier board, and use the correct AC adaptor.
The document also provides detailed technical data such as pin assignments, interface protocols (NMEA 0183), mechanical dimensions, tracking channel count, and environmental specifications. Reference tables compare the different module models and describe soldering, packaging, and shipping guidelines.
| Tracking channels | 22 |
|---|---|
| Interface protocol | NMEA 0183 |
| Power usage | Low |
| Package dimensions (C2626) | 26.00 × 26.00 × 26.00 mm |
| Package dimensions (C1919A) | 19.00 × 19.00 × 2.54 mm |
Approximately 2 seconds after power‑up; commands sent earlier are ignored.
Using an incorrect AC adaptor can damage the product and may void the warranty.
