SMC SY3000/5000/7000/9000 Series Solenoid Valve Product Data Sheet

Technical data sheet for SMC SY3000, SY5000, SY7000, and SY9000 series solenoid valves, covering specifications, flow characteristics, and installation details.

Brand: SMC
Category: Industrial Robot
Document type: Product Leaflet
Language: Chinese
Pages: 11
File format: PDF
File size: 5.9 MB
Updated: 18 October, 2026
MD5 checksum: CE6D0EF7C794C027346F3FFCBA7E48F5
PDF: SMC SY3000/5000/7000/9000 Series Solenoid Valve Product Data Sheet PDF

About this manual

This document provides a product data sheet for the SMC SY3000, SY5000, SY7000, and SY9000 series of solenoid valves. It details technical specifications such as operating pressure, temperature range, response time, and shock/vibration resistance for both 2-position and 3-position valve configurations. This manual is written in Chinese.

What's inside

Product Series
Operating Conditions
Electrical Specifications
Flow Characteristics
Mounting Options
Connection Types
Coil Specifications
Dimensions

Specifications

Standard Compliance	DIN43650C
Shock Resistance Test	No malfunction under drop test
Vibration Resistance Test	45 to 2000 Hz

Frequently asked questions

What voltage options are supported?

Supported voltages include DC 24V, 12V, 6V, 5V, 3V and AC 100V, 110V, 200V, 220V.

Download PDF (5.9 MB)
