Technical specifications for the Siemens 6AV2181-8AV20-0AX0 touch pen system, covering dimensions, materials, environmental limits, and mounting options.
The Siemens 6AV2181-8AV20-0AX0 Touch Pen System is designed for use with both capacitive and resistive touch screens in industrial applications. It includes a pen with a holder, a wall‑mounting bracket, and all necessary mounting hardware.
Key features include an IP65 front protection rating, operation from –40 °C to 80 °C, a compact size (150 mm height, 14 mm thickness, 37 mm enclosure diameter), and a lightweight design (0.13 kg without packaging). The system can be mounted on walls using a bracket, M3 screws, adhesive pads, or a mounting disk.
| IP rating (front) | IP65 |
|---|---|
| Storage temperature range | -40 °C to 80 °C |
| Maximum relative humidity (operation) | 90 % |
| Material (body) | Plastic |
| Attachment cord material | Aluminum |
| Height | 150 mm |
| Thickness | 14 mm |
| Enclosure diameter | 37 mm |
| Weight (without packaging) | 0.13 kg |
| Interconnecting lead length | 53 cm to 100 cm |
It has an IP65 rating at the front.
It can be wall‑mounted using a bracket with a mounting disk, M3 screws, or adhesive pads.
