The QSC CXD‑Q series network amplifiers manual provides safety warnings, installation steps, wiring diagrams, GPIO details and full specifications.
This manual covers the CXD‑Q series of eight‑channel network amplifiers (CXD8.4Q, CXD8.8Q, CXD8.4Qn, CXD8.8Qn). It explains safety precautions, unpacking, rack‑mount installation, power connections, input and output wiring, and how to configure the devices through Q‑SYS software.
Detailed sections describe the front‑panel controls, LED indicators, GPIO pin functions, power‑consumption charts, and the full technical specifications such as power ratings, distortion, frequency response and protection features. The document also includes FCC and RoHS compliance statements and warranty information. This manual is written in Chinese.
| Typical THD (8 Ω) | 0.02 % – 0.05 % |
|---|---|
| Frequency response (8 Ω) | 20 Hz – 20 kHz ±0.3 dB |
| Input impedance | >8 kΩ |
Each CXD‑Q series unit provides eight independent channels (A‑H).
No, the CXD‑Qn models have no analog inputs; they rely on virtual inputs configured in Q‑SYS Designer.
