The Pro-face SP5000 series HMI offers various display sizes, touch options and robust industrial specifications for automation applications.
The SP5000 series from Pro-face provides a range of smart human‑machine interfaces with TFT true‑color LCD screens, resistive multi‑touch panels and optional wireless LAN. Models vary from 7" to 15" displays, each supporting Windows applications and offering high brightness and long‑life LED backlights.
Designed for harsh industrial environments, the units meet IP65F/IP67F protection, operate from 12‑24 VDC, and feature extensive I/O options including USB, Ethernet, serial ports and SD‑card slots. Detailed electrical, environmental and mechanical specifications are provided for each model. This manual is written in Chinese.
| Display size (largest model) | 15" |
|---|---|
| Resolution (15" model) | 1024 x 768 pixels (XGA) |
| Input voltage range | 12~24 VDC |
| Maximum power consumption | 22 W |
| Operating temperature range | 0 °C ~ 60 °C |
| IP protection rating | IP65F / IP67F |
| Weight (15" model) | 3.2 kg |
The SP5000 series operates from 12 VDC to 24 VDC.
The maximum power consumption is 22 W.
It can operate between 0 °C and 60 °C.
The units meet IP65F and IP67F protection standards.
