About this manual

The document is a user manual for the NCP3163 Boost Evaluation Board (NCP3163_Boost_EVB). It describes the NCP3163 DC-DC controller, which supports buck, boost, and inverting configurations with a switching frequency up to 300 kHz. The board is designed to support input voltages from 10V to 20V and provides an output of 24.0V at 700mA. This manual is written in Chinese.

What's inside

Simple Description
Reference Design Evaluation Board
Technical Specifications
Circuit Diagrams
PCB Layout
Bill of Materials

Specifications

Output Voltage	24.0V
Output Current	700mA

Frequently asked questions

What is the maximum output current this device can provide?

The device can provide a maximum output current of 3.4A.

What is the operating temperature range for the standard version?

The standard version operates within a temperature range of 0°C to +70°C.

What is the maximum input voltage rating for this boost converter?

The device supports an input voltage range up to 40V.
