About this manual

The MR-J4 series offers a wide range of servo motors and amplifiers from 50 W up to 55 kW, providing high power, performance, and flexibility for industrial automation. The guide lists compatible motor series, power‑supply requirements, and supported communication interfaces such as EtherCAT®, EtherNet/IP™ and PROFINET®.

Technical data, wiring diagrams, and safety information are presented for each amplifier type (e.g., MR-J4‑B‑RJ, MR-J4‑GF, MR-J4‑TM) along with recommended setup software (MR Configurator2) and environmental limits.

What's inside

Selection Guide Overview
Servo Amplifier Types
Power Supply Options
Communication Interface Options
Technical Specifications
Safety and Protective Functions
Environmental Conditions

Specifications

Rated Output Range	50 W – 55 kW
Main Circuit Power Supply (3‑phase)	200 VAC
Supported Interfaces	EtherCAT®, EtherNet/IP™, PROFINET®
Ambient Temperature Range	0 °C to 55 °C

Frequently asked questions

Is a dynamic brake included in all MR‑J4 amplifiers?

Dynamic brakes are removed from amplifiers rated 7 kW or smaller; larger units may have an external optional brake.
