This manual covers the positioning functions, parameters, and instructions for the Mitsubishi Electric MELSEC iQ-R FX5 series programmable controller.
This manual provides detailed instructions for the positioning functions of the Mitsubishi Electric MELSEC iQ-R FX5 series programmable controller. It covers safety precautions, wiring guidelines, startup and maintenance procedures, and specific positioning control capabilities such as origin return, multi-speed operation, and table running. This manual is written in Chinese.
When the CPU module detects an abnormality via its self-diagnosis function, all outputs turn OFF.
The wiring for forward and reverse limits must use negative logic with NC contacts.
The CPU module grounding terminal must use a wire of 2mm² or larger.
