Installation and maintenance guide for the Mitel 3000 telephone system covering setup, wiring, programming and troubleshooting.
This manual provides detailed instructions for installing the Mitel 3000 PBX, including safety regulations, equipment location, mounting of the CCU, module installation, and system expansion. It also contains FCC information, grounding and surge protection guidelines, and wiring diagrams for connecting phones, T1/PRI lines, and auxiliary devices.
Later sections cover system programming, feature phone configuration, maintenance procedures such as hot‑swapping modules, fault diagnosis, and troubleshooting of common issues. The document includes technical specifications, FCC compliance data, and safety warnings to ensure reliable operation of the telephone system.
| FCC Registration Number | LKCPF09BENCORECX |
|---|---|
| Ringer Equivalence Number (REN) | 0.9B |
| Facility Interface Code (FIC) | 9.0Y |
| Service Order Code (SOC) | 02LS2 |
| USOC Jack Type | RJ11 |
The FCC registration number for the Mitel 3000 is LKCPF09BENCORECX.
The total REN of connected devices should not exceed five (5.0).
It uses a three‑wire grounding type plug with a grounding pin.
