User manual for the Lenovo B816Q 2U blade server covering installation, safety, BIOS setup and specifications.
The Lenovo B816Q blade server is a 2U chassis that holds four X8DTT blade modules, each with dual Intel® 5500 series processors, up to 384 GB of ECC DDR3 memory, and hot‑swap SATA drives. The manual provides product overview, safety guidelines, installation steps, system interfaces, and detailed BIOS configuration.
Additional sections cover advanced motherboard and chassis settings, power supply details, cooling fan control, and appendices with BIOS beep codes, Windows installation instructions, and full system specifications. This manual is written in Chinese.
| Processor | 8 Intel® 5500 Series processors (LGA1366) |
|---|---|
| Memory | Up to 384 GB DDR3 ECC SDRAM (12 × 240‑pin DIMM slots) |
| Power Supply | Two 1400 W 80 Plus Gold certified power supplies |
| Chassis Dimensions | 17.2 × 3.5 × 28.5 in (437 × 89 × 724 mm) |
| Cooling Fans | Four 8‑cm PWM cooling fans |
| RAID Support | RAID 0, 1, 10, 5 |
| Input Voltage | 100‑240 V AC auto‑range |
The B816Q is a 2U chassis that supports four blade modules.
The server supports RAID 0, RAID 1, RAID 10 and RAID 5.
The system accepts an AC input voltage of 100 V to 240 V.
Up to 384 GB of DDR3 ECC memory can be installed across the four blades.
