Keithley 2460 Digital Multimeter Source Measure Unit Product Brochure

A compact, high-power SMU instrument integrating analyzer and I-V system capabilities with a 5-inch touchscreen for intuitive operation.

Brand: Keithley
Category: Other Electronics
Document type: Product Leaflet
Language: Chinese
Pages: 7
File format: PDF
File size: 1.3 MB
Published: 17 October, 2026
Updated: 17 October, 2026
MD5 checksum: B742FFECCC53D6D44E387CC7D3EED2C0
PDF: Keithley 2460 Digital Multimeter Source Measure Unit Product Brochure PDF

About this manual

The Keithley Model 2460 is a digital source measure unit (SMU) that integrates the capabilities of an analyzer, curve tracer, and I-V system into one compact instrument. It features a maximum power output of 100W and supports up to 7A DC/pulse current, making it optimized for testing high-power materials like SiC and GaN. This manual is written in Chinese.

What's inside

Key Features
Applications
Ordering Information
Connectivity
TriggerFlow System
Programming

Frequently asked questions

What is the maximum DC power rating of the Keithley 2460?

The instrument has a maximum DC power rating of 100 W.

What is the maximum current capability of the Keithley 2460?

The instrument can source or sink a maximum current of 7 A.
